CUT130

CUT130

  • Fully dustproof circuit design, Class A protection
  • Fully modular main circuit, more stable
  •  Explosive arc ignition method, instant penetration of thick plates
  •  Single air valve design, 100% arc ignition at 8 kg pressure
  •  Energy-saving cutting nozzle, more efficient than similar products
  • Super strong cutting capacity, maximum cutting width 50mm
  •  Self-locking and non-locking functions, freely adjustable front and rear air pressure
  •  Mesh material cutting function, equipped with CNC interface
  •  Standard cutting width: 30mm, maximum cutting width:

Where To Buy

Product description

  • Fully dustproof circuit design, Class A protection
  • Fully modular main circuit, more stable
  •  Explosive arc ignition method, instant penetration of thick plates
  •  Single air valve design, 100% arc ignition at 8 kg pressure
  •  Energy-saving cutting nozzle, more efficient than similar products
  • Super strong cutting capacity, maximum cutting width 50mm
  •  Self-locking and non-locking functions, freely adjustable front and rear air pressure
  •  Mesh material cutting function, equipped with CNC interface
  •  Standard cutting width: 30mm, maximum cutting width:

Product dimensions

Dimension(mm) 580×280×530mm
Weight(kg) 24.6kg
Voltage(V) 380V
Input current(A) 24.6A
Current range(A) 20-90A
un-load voltage(V) 354V
Rated output power(KW) 10.2KW
Duty cycle 40%
Efficiency 89.55%

  • Fully dustproof circuit design, Class A protection
  • Fully modular main circuit, more stable
  •  Explosive arc ignition method, instant penetration of thick plates
  •  Single air valve design, 100% arc ignition at 8 kg pressure
  •  Energy-saving cutting nozzle, more efficient than similar products
  • Super strong cutting capacity, maximum cutting width 50mm
  •  Self-locking and non-locking functions, freely adjustable front and rear air pressure
  •  Mesh material cutting function, equipped with CNC interface
  •  Standard cutting width: 30mm, maximum cutting width:

Dimension(mm) 580×280×530mm
Weight(kg) 24.6kg
Voltage(V) 380V
Input current(A) 24.6A
Current range(A) 20-90A
un-load voltage(V) 354V
Rated output power(KW) 10.2KW
Duty cycle 40%
Efficiency 89.55%
